Color convex ultrasound scanner ith 6'' touch screen

WiFi-Bluetooth Color Ultrasound Scanner Convex 2-5 MHz 64 Elements, SIFULTRAS-2.0

$2,980.00 $2,145.00

WiFi-Bluetooth Color Ultrasound Scanner Convex 2-5 MHz 64 Elements, SIFULTRAS-2.0

Depth control: Touch screen gesture.

Gain control: Touch screen gesture and physical buttons.

Image processing: Wavelet filter, pseudo color, image smoothing and frame correlation.

Measurement: Depth, length and area.

Measurement accuracy: <=0.5mm (axial), <1mm (lateral).

Image storage: Jpeg, Dicom.

For quantity discounts Please call : +1-323 988 5889>

 × 5 Trees planted for one purchased item

Description

WiFi-Bluetooth Color Ultrasound Scanner Convex 2-5 MHz 64 Elements, SIFULTRAS-2.0

As small as an iPhone, WiFi-Bluetooth Color Ultrasound Scanner Convex 2-5 MHz 64 Elements, SIFULTRAS-2.0 packs stunning technologies and innovations to offer convenient imaging whenever and wherever needed.

SIFULTRAS-2.0 can be widely used in medical applications like hospital clinical treatment, emergency medicine, primary care, obstetrics and gynecology, guided procedures for injections, aspirations, vascular access, and line placement, as well as remote medicine. WiFi-Bluetooth Color Ultrasound Scanner Convex 2-5 MHz 64 Elements, SIFULTRAS-2.0 fills in gaps of lack of ultrasound image equipment for basic medical institutions.

And it plays more and more important roles for improving point-of-care, clinical diagnostic methods and efficiency of clinic diagnosis, due to its innovation features like WiFi-Bluetooth  connection (3G/4G/WiFi), full touch screen and easy-to-use interface for non-radiologist usage, online and offline on-device technical training as well as remote cloud support for reading ultrasound image and guidance for operation.

       Features:

  • Pocket size medical smart ultrasound scanner with high speed cellular and Wifi data communication  capability.
  • Clear and rapid imaging for intervention guidance.
  • Special designed full touch UI for each individual application and easy to operation without special training.
  • Automatically syncing data to private cloud for telemedicine and mobile telemedicine.
  • Android sw operation system to make the applications easy for extendable.
  • Enables ultrasound whenever and wherever necessary.



      Specifications:

      Ultrasound Acoustics:

  • Imaging mode:   B
  • Frame rate:     >=16 fps
  • Transducers:     Electronically focused convex probe (3~5MHz)
  • Element count:    64
  • Image depth:     <=20 cm
  • Dynamic gain control range:   >120 dB
  • Video replay:   32 or 64 fps

      Device Electrical and Mechanical Spec:

  • CPU: 1.2GHz Quad-core Cotex A9.
  • OS: Android 4.3.
  • Display: 6.0 inch with 720*1280 resolution.
  • Touch screen: Capacitive TP.
  • Camera: 5M pixels.
  • Memory: 1/2GB LPDDR2 + 8/16/32GB Flash.
  • Cellular Network: Optional (3G/4G).
  • Connectivity: BT 3.0 EDR, WiFi & WAPI, GPS&AGPS.
  • Radio: Stereo FM radio.
  • Interface: Micro USB 2.0 HS (w/ charging), 3.5mm audio jack.
  • Sensor:  Accelerometer, P/L sensor, E-compass, Gyroscope.
  • Keypad: Power, Freeze and Gain +/-.
  • Battery: 5000mAh, up to 3 hours ultrasound continuous scans.
  • Dimension: 158mmx84mmx20mm



Wireless convex Ultrasound Machine , SIFULTRAS-5.52
Wireless convex Ultrasound Machine , SIFULTRAS-5.52

SIFULTRAS

Certifications

CE
ISO13485
This product is not to be used in  The US .

1 × WiFi-Bluetooth Color Ultrasound Scanner Convex 2-5 MHz 64 Elements, SIFULTRAS-2.0
1 × User Manual
12 Months Warranty
