Depth control: Touch screen gesture
Gain control: Touch screen gesture and physical buttons
Image processing: wavelet filter, pseudo color, image smoothing and frame correlation
Measurement: Depth, length and area
Measurement accuracy: <=0.5mm (axial), <1mm (lateral)
Image storage: Jpeg, Dicom
As small as an Iphone, SIFULTRAS-2.0 packs stunning technologies and innovations to offer convenient imaging whenever and wherever needed.
SIFULTRAS-2.0 can be widely used in medical applications like hospital clinical treatment, emergency medicine, primary care, obstetrics and gynecology, guided procedures for injections, aspirations, vascular access,
and line placement, as well as remote medicine. SIFULTRAS-2.0 fills in gaps of lack of ultrasound image equipment for basic medical institutions in China and the third world countries.
As well, it plays more and more important roles for improving point-of-care, clinical diagnostic methods and efficiency of clinic diagnosis, due to its innovation features like WiFi-Bluetooth connection (3G/4G/Wfi), full touch screen and easy-to-use interface for non-radiologist usage, online and offline on-device technical training as well as remote cloud support for reading ultrasound image and guidance for operation.
· The world first pocket medical smart ultrasound scanner with high speed cellular and Wifi data communication capability.
· Clear and rapid imaging for intervention guidance.
· Special designed full touch UI for each individual application and easy to operation without special training.
· Automatically syncing data to private cloud for telemedicine and mobile telemedicine.
· Android sw operation system to make the applications easy for extendable.
· Enables ultrasound whenever and wherever necessary.
Imaging mode: B
Frame rate: >=16 fps
Transducers: Electronically focused convex probe (3~5MHz)
Element count: 64
Image depth: <=20 cm
Dynamic gain control range: >120 dB
Video replay: 32 or 64 fps
Device Electrical and Mechanical Spec
CPU: 1.2GHz Quad-core Cotex A9
OS: Android 4.3
Display: 6.0 inch with 720*1280 resolution
Touch screen: Capacitive TP
Camera: 5M pixels
Memory: 1/2GB LPDDR2 + 8/16/32GB Flash
Cellular Network: Optional (3G/4G)
Connectivity: BT 3.0 EDR, WiFi & WAPI, GPS&AGPS
Radio: Stereo FM radio
Interface: Micro USB 2.0 HS (w/ charging), 3.5mm audio jack
Sensor: Accelerometer, P/L sensor, E-compass, Gyroscope
Keypad: Power, Freeze and Gain +/-
Battery: 5000mAh, up to 3 hours ultrasound continuous scans
1 × SIFULTRAS-2.0 Convex Probe Portable Wifi Ultrasound Scanner,2-5 MHz, 64 Elements
10 × We plant for you ten Trees
12 Months Warrant
× 5 Trees planted for one purchased item
